Invert4geom#
Invert4geom is a Python library for performing 3D geometric gravity inversions, where the aim is to recover the geometry of a density contrast.
Typical use cases include modeling the topography of the Moho, the sediment-basement contact, or bathymetry. These density contrasts are represented by a layer of vertical right-rectangular prisms. Since we use vertical prisms, they don’t take the curvature of the Earth into account. For large-scale applications, such as continental studies, it would be better to use tesseroids instead of prisms.
See the overview for further description of this package and what it can be used for.
){kind=icon}
Ready for daily use but still changing.
This means that we are still adding a lot of new features and sometimes we make changes to the ones we already have while we try to improve the software based on users’ experience, test new ideas, make better design decisions, etc. Some of these changes could be backwards incompatible. Keep that in mind before you update invert4geom to a new major version (i.e. from v1.0.0 to v2.0.0).
What Invert4Geom is for:#
invert gravity data to recover the topography of a density contrast
use with gridded gravity data
discretization using vertical right-rectangular prisms
performing regional-residual separation
stochastic uncertainty analysis of inversion results
basic visualization tools
What Invert4Geom is NOT for:#
performing parameter-estimation inversions (i.e. recovering density values) -> see SimPEG or pyGIMLi
a point-and-click GUI -> see Geosoft/Seequent Oasis Montaj or MiraGeoscience VPmg
a ready-to-use inversion with minimal user input
use with discrete (un-gridded) gravity data -> see Harmonica for gridding your data
for processing gravity data -> see Harmonica for gravity processing tools
for use with tesseroids, or non-regular grids (raise an issue request if you want this implemented!)
publication-quality visualization -> see PyGMT for plotting tools
How to contribute
I really welcome all forms of contribution! If you have any questions, comments or suggestions, please open a discussion or issue (feature request) on the GitHub page!
Also, please feel free to share how you’re using Invert4Geom, I’d love to know.
Please, read our Contributor Guide to learn how you can contribute to the project.
Note
Many parts of this documentation was adapted from the Fatiando project.
